最高110GHz射频连接器，VSWR最低1.002，插入损耗0.05dB

时间： 2023-03-10 来源：世强

技术问答

选型帮助

研发客服

商务客服

射频技术已经基站建设、汽车、测试计量、医疗等行业中发挥重要作用，射频连接器也开始向电气自动化、高频高速、小型化、智能化和精密化等方向发展壮大。世强联合国内外著名厂商带来各类高品质射频连接器，其中有TE最高达110GHz的射频同轴N系列连接器，IMS的MCA系列高速数据连接器VSWR最低1.002，中电科40所的射频连接器插入损耗≤0.05db。

品牌及产品介绍

全球最大的连接器制造商＆传感器行业龙头企业——TE connectivity

射频同轴SMA连接器：性能达到12.4GHz及更高，有多种贱金属可供选择，包括不锈钢、黄铜和锌压铸，可提供耐腐蚀、无磁性的白青铜镀层，满足所有性能要求MIL-C-39012。

射频同轴N系列连接器：泰科电子N连接器具有15.88-24螺纹接头，可实现最佳稳定性，非常适合关键应用和环境。中等尺寸的连接器可以承受冲击和振动，以确保低噪音水平，并具有50欧姆的恒定阻抗，具有俘获中心触点，并在高达110GHz的频率和1000伏均方根电压下提供出色的性能。

微型射频同轴连接器：SMT/QuickGrip设计为可能遇到冲击、振动和/或电缆弯曲的应用提供最佳的电缆保持力。这种独特的RF设计接受柔性和半刚性微同轴电缆，同时提供高达 3GHz的卓越RF性能。

射频同轴连接器：最高带宽DC110 GHz，极低的插入损耗，电压驻波比最低1.15，在BNC/N/SMA三种接口中拥有多种标准组合，如3.5mm/2.92mm/2.40mm/1.85mm/1.35mm/1.0mm等。

【选型】TE Connectivity（泰科）射频同轴电缆连接器选型指南

高性能射频连接器、线缆组件、测试转接器以及测试线缆组件生产商——IMS（亿迈通讯）

MCA系列高速数据连接器：传输速率高达20Gbit/s、频率达15Ghz，被称为Mini-FAKRA、驻波比≤1.002。

HSD连接器：数据传输率可达5Gbit/s，频率高达2GHz；阻抗100Ω，有效防止信号串扰和外部信号干扰，很强的LVDS数据传输能力。

NEX10连接器：具有低PIM和坚固耐用的设计，尺寸紧凑，可满足即将到来的小型电池空间缩减要求。频率范围0-40GHz；互调≤-168dBC。

【选型】IMS（亿迈通讯）同轴连接器（射频同轴连接器/高频同轴电缆）

【选型】IMS（亿迈通讯）MCA系列高速数据连接器

【选型】IMS（亿迈通讯）汽车制造业用HSD连接器/SMBA®连接器（FAKRA）

中国电子行业接插件与继电器专业研究所——中电科40所（CETC40）

射频连接器：频率达46GHz，插入损耗：≤0.05db，驻波比：≤1.1、耐温-65℃~+165℃、产品质量完全满足国军标要求，可非标定制。

SSMP系列连接器：是一种超小型推入式射频同轴连接器，它比SMP小30%，尺寸约为SMA连接器的70%，可以在轴向漂移±0.2mm，径向偏移为直径在0.5mm范围内保持可靠连接。

ASMP：是一种与SMP结构形式相同的新型盲插式射频连接器，使用方法与SMP相同，外形尺寸比SMP大22%左右，算数功率比SMP大30%~50%。

【选型】中电科40所（CETC40）新能源汽车用连接器选型指南

【选型】中电科40所（CETC40）射频连接器/口径变换微波模块/射频电缆组件选型指南

全球领先的RF（射频）、微波和毫米波互连解决方案提供商——Delta（德尔特）

射频连接器SMP系列：是PC板到板互连以及模块到模块互连的最佳选择，具备体积小、频率高、接触可靠，抗振动等优点，标准阻抗50Ω，频率范围：DC-40GHz，电压驻波比：最大1.20至26.5GHz；最大1.5至65GHz，绝缘电阻：5000MΩ，在海平面的DWV：120Vrms，射频泄露参数：-80db to 3GHz，-65db to 26.5GHz。

射频连接器SMPM系列：在功能上与SMP系列相似，但尺寸比SMP系列小30%，提供DC-65GHz工作频率范围。中心距减少到0.125英寸。这使得SMPM系列在更高密度微波应用中具有明显的优势，长度方向支持客户定制。

射频连接器SMP3系列：相比SMPM产品体积小30%，是同系列中体积最小的产品线，中心距仅为0.085英寸，最小板对板间距为0.125英寸，标准阻抗50欧姆，频率范围：DC-65GHz，电压驻波比：最大1.20至26.5GHz；最大1.5至65GHz，绝缘电阻：3500兆欧。

【选型】德尔特（Delta）SMP/SMPM/SMPS 65 GHz高性能连接器选型指南

【产品介绍】Delta’s SMP3 Connector Product Introduction

M2M领域解决方案的全球领导者，品类齐全，可定制——TAOGLAS（陶格斯）

Taoglas的产品组合包括SMA、FAKRA、MMCX和NMO电缆安装连接器，针对各种电缆类型和PCB安装要求，Taoglas有SMA、MCX和MMCX连接器。

RJ45系列集成连接器提供种类丰富的产品，设计用于商业级应用和工业级应用，支持10/100 Base-T（Atmos100系列）和1G Base-T（Atmos100系列）速度。这些表面贴装或通孔组件提供高可靠性能，能始终保持信号完整性，符合IEEE 802.3标准和UL认证。以太网供电选项还包括PoE、PoE+和PoE++，波峰/回流温度250℃@5秒。

2.92连接器和适配器均可与其他行业标准连接器交叉匹配，支持直流和高达40GHz的频率。壁厚也比标准SMA连接器厚，适配器类别还包括2或4孔面板安装、PCB垂直安装和PCB边缘安装配置。符合RoHS Reach标准。

【选型】Taoglas（陶格斯）射频连接器/转接器/插座选型指南

【选型】Taoglas（陶格斯）RJ45连接器选型指南

【选型】Taoglas（陶格斯）2.92毫米波适配器和连接器选型指南

全球顶端的无线射频和光纤通信技术制造商——ROSENBERGER（罗森伯格）

罗森伯格的HFM®高速FAKRA-Mini 连接器是汽车行业性能最佳的“Mini-Coax”连接器系统。同轴连接器系统可应用于高达20GHz的频率，智能模块化设计可确保高达28Gbps的高数据速率的快速传输，与传统的Fakra连接器类型相比，非常小的尺寸可节省高达80%的空间。

【选型】Rosenberger（罗森伯格）射频连接器/电缆组件/转接器/校准件/测试测量选型指南

【产品】罗森伯格高性能射频连接器HFM高速FAKRA-Mini，支持高达28Gbps的高数据速率传输

提供安全可靠的连接解决方案——深台帏翔（STWXE）

Fakra连接器：包含单体&四合一Fakra，符合FAKRA标准及USCAR要求，耐温-45℃~+105℃，VSWR：1.25&DC0-3GHz；1.5&DC3-6GH，应用于车联网、车载多媒体、GPS、移动通讯、胎压监测等。

【选型】深台帏翔（STWXE）高速连接器选型指南

专业微波射频天线和电气信号连接器制造商——金航标（Kinghelm）

FF连接器：工作温度-25℃~85℃，额定电压50V（AC和DC等效），接触电阻≤0.03Ω，绝缘电阻≥500MΩ

射频连接器：特性阻抗：50Ω，绝缘耐压：≥1000V，频率范围：DC-6GHz，机械寿命：500 次（每分钟12次），环境温度：-55~+155℃

金航标专注研发生产数据信号连接器接插件接口板端等产品，更好为车联网物联网行业终端客户服务

【产品】频率范围0～6GHz的微型射频连接器KH-3030175-G1，适用于射频电路

世界电气连接和工业自动化行业巨头——Phoenix Contact（菲尼克斯电气）

板对板连接器FINEPITCH：可广泛应用于设备内部数据传输，间距范围0.5mm~2.54mm，堆叠高度可供客户任意选择，满足EMC电磁屏蔽功能，500次插拔循环抗，50g的振动冲击，最高数据传输速率25Gbps

RJ45：数据传输速率高达10Gbps，符合CAT6A标准，接线容量：AWG 22 至AWG 26（刚性和柔性），适用于外径9mm的电缆，使用IDC技术，快速免剥线连接。

【选型】PhoenixContact（菲尼克斯电气）固定式连接器和插拔式连接器选型指南

【选型】PhoenixContact（菲尼克斯电气）传感器/执行器和工业级重载连接器选型指南（第2册）

SMA射频连接器：SMA四脚座子母头SMA-KE反极RP-大角偏角。

标准阻抗50欧姆，频率范围：0~12.4G，电压驻波比：＜1.15+0.02fGHz，绝缘电阻：大于5000兆欧。插入损耗1.5dB。工作温度：-65℃~165℃。插拨次数：≥500，可耐压：1500V。

【选型】蝙蝠无线（BAT WIRELESS）射频器件选型指南

类别齐全的物联网IOT器件生产制造商,可专案开发定制——众驰（zhongchi）

多种射频连接器：SMA、SMB 、MMCX、MCX、BNC、F头、FAKRA可开发定制。

频率覆盖范围DC~3GHz，VSWR电压驻波比不超过1.3，工作温度范围-65℃~165℃，符合IEC60169-4标准。工作温度：-65℃~165℃。插拨次数：≥500，可耐压：1500V。

【选型】众驰（zhongchi）RF射频连接器选型指南

【产品】特性阻抗50Ω的SMA正脚母头射频连接器ZC8.818KK，频率覆盖范围为DC~3GHz

中国大陆唯一的CPU Socket连接器供应商、国产连接器的龙头企业——得润电子（DEREN）

BNC卡口系列产品具有连接迅速可靠的特点，标准阻抗50Ω~75Ω，频率范围：DC-4GHz，耐压≥1000V，电压驻波比可按客户要求，温度范围-40~+155℃

N螺纹连接系列产品具有连接可靠、抗振性强、性能优越的特点，标准阻抗50Ω~75Ω，频率范围：DC-11GHz，耐压≥1000V，电压驻波比可按客户要求，温度范围-40~+155℃
MCX插入连接系列产品具有连接迅速、接触可靠、性能优良的特点标准阻抗50Ω，频率范围：DC-6GHz，耐压≥750V，电压驻波比可按客户要求，温度范围-40~+155℃

专业的连接器制造商——格康电子（Greenconn）

射频同轴连接器：耐性可达到500r/min，可随产品移动，电压波速比最大可达到1.5，讯号完整，不收外界影响。可在-40℃~90℃工作，满足严苛环境，使用寿命长达5年。

【选型】格康电子（GREENCONN）高频连接器与线材选型指南

国内首家集射频互联、自动化、软件、PCB设计及测试于一体的定制化方案商——德普福（Dloorplf）

SMA母头射频同轴连接器：使用2颗M2螺钉锁紧，阻抗50Ω，频率范围为DC~18GHz，工作温度范围为-40℃~+105℃，符合RoHS标准

板端连接器：具有性能优、高可靠、寿命长的特点。适用于微波设备和数字通信系统的射频回路中连接射频电缆或微带线。该同轴连接器支持的频率范围为DC~27GHz，阻抗为50Ω，工作温度范围为-40℃~+150℃

【选型】国产SMA射频连接器RJ0S-1D-S12用于老化测试板，频率范围0~26.5GHz

【产品】频率范围DC~27GHz的德普福同轴连接器RJ0S-0D(SMA-KM01)，阻抗达50Ω

具有军工品质的稳相微波电缆制造商——军友射频（JunCoax）

连接器：驻波小，性价比高，性能稳定可靠，经济耐用，寿命长，适用于高低温

精密测试连接器频率为DC-40Ghz，阻抗为50Ω，温度范围-55℃~+125℃，具有宽频带，低驻波，低损耗，可按客户要求设计和生产等特点。

【选型】军友射频（JunCoax）精密同轴连接器选型指南

【选型】军友射频（JunCoax）SMP系列微小型同轴连接器选型指南

IoT物联网射频核心部件供应商——骏晔科技（DreamLNK）

SMA转KE射频同轴连接头、高品质射频同轴连接头：增强导电性、抗氧化耐腐蚀、材质环保安全、镀真金离子、性能稳定、耐用性强。应用范围如无线通讯、运营商网络以及检测测量仪器等，用作射频信号的连接。使用频段为0~6GHz、阻抗为50Ω、最大驻波比≦1.4、功率为10W、工作温度在-45~80℃。

【选型】骏晔科技（DreamLNK）胶棒天线/吸盘天线/FPC天线/弹簧天线/连接头、线/陶瓷天线选型

【产品】体积小，低vswr的SMA转KE射频同轴连接头SMA-KE-P902，使用频率可以达到25GHz

专业宽带微波及毫米波器件制造商——扩维（Qualwave）

夹板式免焊连接器：频率：DC~67GHz，驻波不超过1.35，温度：-55~+165℃，采用1.85mm射频连接器，免焊接、可重复使用、安装简便等特性，适用于各类测试场合，经济耐用。

电路板连接器，可拆卸式，2.4mm公头，DC~50GHz，2-4孔法兰，不锈钢，不同尺寸可以选择。

扩维（Qualwave）耦合器/连接器选型表

【选型】扩维（Qualwave）电路板连接器选型指南（中文）

实现自动化生产和检验，开关日产能400万只，针座日产能200万只 ——华灿天禄（HCTL）

板端射频系列：IPEX接口类型：内针，端口数量：1，阻抗：50Ω，频率-最大值：6GHz，接口直径：1.4mm，工作温度范围：-40℃~+90℃，IPEX天线座RF同轴连接器（天线座）

3.2.08.0112 HC-RF-IPEX2020-03 RF III Receptacle Assembly (H=0.85mm)
