【产品】耐高纹波电流低ESR铝电解电容，直流耐压可达500V

时间： 2019-02-07 来源：Kendeil

代理服务

技术支持

采购服务

KENDEIL是生产大功率逆变器应用电子元器件的领先生产商，有超过37年的设计生产经验。其推出的铝电解电容 K25和K26系列，采用带绝缘套管的铝制封装，并针对高纹波电流和低ESR(等效串联电阻)应用进行了优化，适用于超紧凑型UPS，太阳能逆变器，高纹波电流转换器和电机驱动器。

K25系列电解电容具有较高的耐压值，额定直流工作电压范围为400V~500V，工作温度范围为-40℃～105℃。K25系列额定电压为400~450V的型号，额定电容值范围为820μF~2200μF，在温度105℃条件下，使用寿命长达8000小时。当工作频率大于10kHz时，最大允许纹波电流为1.55Ir（额定纹波电流Ir）；当环境温度为35℃时，最大允许纹波电流为3.0Ir。K25系列额定电压为500V的新型号，针对低ESR和高纹波电流进行了优化设计，电容值范围为220μF~1200μF，在温度105℃条件下，使用寿命为5000小时。

K26系列电解电容与K25系列的耐压值一样，额定直流工作电压范围为400V~500V，工作温度范围为-40℃～85℃。K26系列额定电压在400~450V的型号，额定电容值范围为1000μF~2700μF，在温度85℃条件下，使用寿命长达12000小时。当工作频率大于10kHz时，最大允许纹波电流为1.55Ir（额定纹波电流Ir）；当环境温度为35℃时，最大允许纹波电流为2.2Ir。K26系列额定电压为500V的新型号，针对低ESR和高纹波电流进行了优化设计，电容值范围为330μF~1700μF，在温度85℃条件下，使用寿命为10000小时。

K25和K26系列包含3种封装，根据电容容值而定。

图1 K25和K26封装图

K25和K26系列主要特点：

•采用带绝缘套管的铝制防浪涌电容器

•针对低等效串联电阻和高纹波电流进行了优化设计

•卡入式PCB安装端子

•额定工作电压范围400V~500V DC

•工作温度范围宽（K25系列为-40℃～105℃，K26系列为-40℃~+85℃）

K25和K26系列应用：

•超小型不间断电源

•太阳能逆变器

•高纹波电流转换器

•电机驱动器
