全球弹簧夹持连接技术的领导者：WAGO（万可）

时间： 2020-04-22 来源：世强

技术问答

WAGO（万可）成立于1951年，总部在德国，是弹簧夹持连接技术的先驱者与领导者，致力于打造以弹簧夹持连接技术为核心的轨装式接线端子,印刷电路板连接器,工业接插件,工业接口模块及分布式自动化控制组件及软件等。自1997年进军中国以来，WAGO（万可）曾获得2018IMIC智能创新产品奖及最佳人气奖，第18届中国电气工业生产力十强，第十六届中国自动化及智能化智造领袖奖等多项荣誉，并与万科，中车等名企建立了合作关系。

服务与支持：线上商城技术资料

授权代理商：世强先进（深圳）科技股份有限公司 - 查看

品牌官网：https://www.wago.com/global/

主要产品：PCB端子板对板连接器 PCB接插件 USB连接器 RJ45连接器导轨端子继电器电源浪涌保护器交换机 I/O模块传感器执行连接器模拟信号隔离器电缆组件

主要应用：电梯,电力控制系统,轨道交通,风能,太阳能,照明,造船,仪器仪表,机械制造,建筑布线,工业机器人,锂电自动化设备,3C电子设备,汽车自动化设备,半导体设备,激光设备,机床设备

● 完整、高性能接线端子系列，适合多种应用

● 全球首创的操作杆式轨装式端子，醒目的橙色手柄易于识别，且操作方法简单

● PUSH IN直插式连接技术，适用于所有类型导线，硬线可直插

● 导流条为电解铜镀锡材质，拥有良好的导电性能，且抗腐蚀，抗盐雾等化学物质

PCB接线端子及MCS多用途连接器

● PUSH IN直插型笼式弹簧连接技术，接线简单、便捷

● 接线面积从0.08到16mm²可选，焊针间距从2.5至20mm，品类齐全

● SMD PCB接线端子，外形紧凑、扁平、简洁，单股导线可直接插入，卷装

● 插拔式PCB连接器可提供单独焊针和焊针条两种类型，载流能力最高41A

● 直插式大功率PCB接线端子，额定电流最高76A

自动化控制技术产品系列

● 完整的软件解决方案，可满足几乎所有行业标准，并集成标准现场总线

● 触控面板（HMI面板），简化机器、系统和控制技术领域的数据处理和监控，可处理复杂的自动化系统任务

● PLC控制器，超高性能、低功耗、多接口，可使用e!COCKPIT (CODESYS 3)和CODESYS 2进行编程

● IP20和IP67远程I/O系统，兼容几乎所有标准现场总线协议和ETHERNET标准

● 工业以太网交换机，稳定、可靠、冗余符合IEEE 802.3、IEEE 802.3u和IEEE 802.3ab标准。

● 传感器/执行器接线盒，IP67/IP68等级，防尘防潮，抗震动抗冲击

工业接口模块

● 继电器和光电耦合器模块，品类齐全，连接截面积从0.34到2.5 mm²

● 模拟信号转换模块，隔离、放大、滤波、转换，安全隔离，符合DIN EN 61010-1标准

● 电源模块，拥有UPS模块、缓冲模块、冗余模块、电子断路器完整的供电系统，满足多种应用

● 电流互感器和电压测试头，品类丰富，采用安全、可靠的笼式弹簧连接技术
