优恩半导体过压过流保护器件的特性优势及应用
优恩半导体防护器件分为过压保护和过流保护,过压保护产品主要有ESD静电二极管(ESD)、瞬态抑制二极管(TVS)、陶瓷气体放电管(GDT)、半导体放电管(TSS)、压敏电阻(MOV)、贴片压敏电阻(MLV)、玻璃气体放电管(SPG)等,过流保护产品主要自恢复保险丝(PTC)、熔断保险丝等;优恩半导体在防护器件领域,立足于半导体类过压防护器件的设计、制造、应用及技术服务,主要产品涵盖TVS系列、ESD系列、GDT系列、TSS系列、MOV系列、SPG系列、PPTC系列、集成防护器件等等。
优恩半导体过压过流保护器件主要特性和优势:
· 产品种类齐全
· 响应速度快
· 电压精确
· 可重复
优恩半导体过压过流保护器件主要应用:
· 安防行业: POE防护,RJ45防护,AC/DC电源防护,I/O,数据线,DVR/NVR等接口;
· 汽车电子:ABS、CAN-BUS、车窗升降器、雨刮器、车用充电器、车载DVD影音像系统、GPS定位仪、汽车仪表;
· 通讯行业:基站,电话机,传真机,POS机、Modem,xDSL终端,程控交换机局端设备,RS232/422/423/485、10/100M Ethernet、Gigabit Ethernet,CATV设备
· 仪器仪表:智能电表、水表、气表等远程抄表仪器、仪器电源端口、
· 消费类电子:USB、HDMI、I/O口、DC电源口、射频口等
· 其他领域:共模/差模保护、RF 耦合/IC 驱动接收保护、电机电磁波干扰抑制、声频/视频输入、传感器/变速器、工控回路、继电器、接触器噪音的抑制。
- |
